European UAP Channels

Click headers to sort.

Designation



Mass per
metre

kg/m
Depth of
section
h
mm
Width of
section
b
mm
Thickness
of web
s
mm
Thickness
of flange
t
mm
Root
radius

mm
Nearest UK
section


UAP 80 8.4 80 45 5 8 8 n/a
UAP ChannelsUAP 100 10.5 100 50 5.5 8.5 8.5 100 x 50 PFC
UAP ChannelsUAP 130 13.7 130 55 6 9.5 9.5 125 x 65 PFC
UAP ChannelsUAP 150 17.9 150 65 7 10.25 10.25 150 x 75 PFC
UAP ChannelsUAP 175 21.2 175 70 7.5 10.25 10.25 180 x 75 PFC
UAP ChannelsUAP 200 25.1 200 75 8.0 11.5 11.5 200 x 75 PFC
UAP ChannelsUAP 220 28.5 220 80 8 12.5 12.5 230 x 75/90 PFC
UAP ChannelsUAP 250 34.4 250 85 9 13.5 13.5 260 x 90 PFC
UAP ChannelsUAP 300 46.0 300 100 9.5 16 16 300 x 100 PFC
